PET Film 0.5mm Sheet White ESD Matt Rigid PET Film Roll For Thermoforming
You are here: Home » Products » Plastic Film Product » PET Film » PET Film 0.5mm Sheet White ESD Matt Rigid PET Film Roll For Thermoforming

loading

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

PET Film 0.5mm Sheet White ESD Matt Rigid PET Film Roll For Thermoforming

Industrial Use Business&Shopping
length Other, 50M, 300M, 100M
Width 50cm, 30cm, Other
Hardness Rigid
Processing Type Multiple Extrusion
Transparency Opaque
Brand Name sunyo
Model Number SY3041
Surface smooth, High Gloss, GLOSSY, Other
Product name ESD Matt Rigid PET Film Roll For Thermoforming
Color Clear or can be customized
Feature Waterproof
Density 1.37-1.43g/cm3
Application Vacuum thermoforming
Width in roll 300~1300mm
Length Can be customized
Certificate ROSH REACH EN71
Environment Eco-friendly
Availability:
Quantity:
Inquire Add to Basket

  • Yeejyun

Specification

Specification date: Thickness:100micron,125micron,150micron,188micron,200micron,250micron,300micron,350micron Width:8-2000mm

Item
Unit
Value
Test condition
Thickness
Um
100
125
175
188
200
350
GB/T13542.1-2009
Tensile strength
MD
Mpa
196
179
180
182
182
171
GB/T13542.2-2009
TD
200
190
205
193
195
177
Elongation at break
MD
%
131
137
165
170
176
185
GB/T13542.2-2009
TD
100
114
112
110
106
115
Heat shrinkage
（150℃,30min）
MD
%
1.5
1.5
1.5
1.5
1.5
1.5
GB/T13542.2-2009
TD
0.5
0.5
0.5
0.6
0.7
0.5
Haze
%
25
28
42.3
44.6
46.5
55.1
GB/T2410-2008
Electrical strength
V/um
123
105
97
87
80
72
GB/T13542.2-2009
Volume resistivity
Ω.m
1.3X1015
GB/T13542.2-2009
Dielectric loss tangent
（50Hz）

2.5X10-3
GB/T13542.2-2009
Relative dielectric constant
（50HZ）

3.4
GB/T13542.2-2009



Product Description

0.19mm Translucent Milky White Color PET  Mylar Film Mylar Stencil Sheet

PET is milky white with smooth and shiny surface.In a wide range of temperature has excellent physical and mechanical properties, long-term use temperature up to 120℃, excellent electrical insulation, even at high temperature and high frequency, its electrical properties are still good, creep resistance, fatigue resistance, friction resistance, dimensional stability are very good. Application: Used for label of pressure-sensitive adhesive,electronics ,motor and generator insulation, can also be used for electrical wires, cables insulation layer,Slot and coil insulation of motor,separate insulating base material between the coils of dry transformer etc

Features: Shading light,white,outstanding mechanical strength,excellent resistance to heat.
